Polyoxymethylene
Product Details:
| Place of Origin: | China |
| Brand Name: | XIN LIAN XIN |
| Certification: | Q/XXLX 0010-2024 |
| Model Number: | Polyoxymethylene |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20t |
|---|---|
| Price: | To be communicated |
| Packaging Details: | 25KG |
| Delivery Time: | To be communicated |
| Payment Terms: | L/C, T/T |
|
Detail Information |
|||
| Melt Flow Rate，g/10min: | 9.0±1.0 | Notched Impact Strength，KJ/m2: | ≥5.5 |
|---|---|---|---|
| Yield Stress，MPa: | ≥58 | Nominal Strain At Break，%: | ≥30 |
Product Description
Performance Characteristics of Polyoxymethylene (POM):
High Strength and Rigidity: POM has high tensile strength and rigidity, making it highly effective in bearing mechanical loads with excellent performance.
Wear Resistance:
Due to its molecular chain structure, POM exhibits outstanding wear resistance in frictional environments, making it ideal for applications such as gears, bearings, and other components subject to wear.
Low Friction Coefficient:
POM has a low coefficient of friction, making it suitable for sliding, rolling, and load-bearing applications, such as pulleys, bearings, and other similar parts.
Excellent Dimensional Stability:
POM maintains excellent dimensional stability over a wide temperature range, making it suitable for precision machining applications.
Chemical Resistance:
It has good resistance to most common solvents, oils, fuels, and chemicals, making it suitable for use in harsh environments.
Outstanding Electrical Insulation:
POM has good electrical insulating properties, widely used in the electronics and electrical industries.
Main Types:
Homopolymer:
Offers higher rigidity, strength, and wear resistance, suitable for high-load applications.
Copolymer:
Offers better toughness and impact resistance, suitable for more complex processing requirements.
| Grade | X-25 | X-50 | X-90 | X-130 | X-270 |
Characteristic |
Medium and low flow standard type |
Medium and high flow standard type |
Medium flow standard type |
Medium and high flow standard type |
high flow standard type |
Applications |
Plates, bars, bearings, gears, rollers, pump parts, valve parts, etc. |
Plates, bars, bearings, gears, rollers, pump parts, valve parts, etc. |
Electronic and electrical equipment, bearings, gears, fasteners, etc. |
Electronic and electrical equipment, zipper,fastener, etc. |
Electronic and electrical equipment, zipper,fastener, etc. |
state |
White Granular |
White Granular |
White Granular |
White Granular |
White Granular |
Processing method |
Injection molding, extrusion molding |
Injection molding, extrusion molding |
Injection molding, extrusion molding |
Injection molding, extrusion molding |
Injection molding, extrusion molding |
| Physical properties | Values | ||||
| Density g/cm3 ISO 1183-1 |
1.40 | 1.40 | 1.40 | 1.40 | 1.40 |
| Melt Flow Rate(190℃/2.16kg) g/10min ISO 1133-1 | 2.5 | 5.5 | 9.0 | 13.0 | 27.0 |
| Mechanical properties | Values | ||||
| Tensile Strength Mpa ISO 527-1,2 |
58 | 59 | 61 | 62 | 63 |
| Nominal strain fracture % ISO 527-1,2 |
38 | 38 | 35 | 33 | 30 |
| Tensile modulus Mpa ISO 527-1,2 |
2400 | 2400 | 2600 | 2600 | 2700 |
| Flexural strength Mpa ISO 178 |
80 | 80 | 90 | 90 | 89 |
| Charpy notched impact strength(23℃) KJ/m2 ISO 179/1eA |
8.0 | 7.0 | 6.0 | 5.5 | 5.0 |
Injection moulding processing conditions |
|||||
Drying temperature:80-90℃,Drying time:3-4 hours Processing temperature:Nozzle temperature:180-210℃；Front of Barrel:190-210℃；Middle of Barrel:170-200℃； behind of Barrel:160-180℃； Melt temperature: 180-210℃；Mold temperature: 60-90℃ (precision mold temperature can be increased to 120℃) Pressure: Injection pressure: 50-100MPa; Holding pressure: 30-80MPa; Back pressure: 0-0.5MPa Screw speed: 50-120 rpm |
|||||
